Armstrong Pumps 174034MF-013 Circulator Pump (H-32 BF) 1-Phase 1/6Hp 115V 60 Hz

Name: Armstrong Pumps 174034MF-013 Circulator Pump (H-32 BF) 1-Phase 1/6Hp 115V 60 Hz
Brand: Armstrong Pumps
SKU: 174034MF-013
Price: 1107.52 USD
Availability: InStock
Rating: 5 (1 reviews)

Images for general purposes only. Actual may be different than depicted.

Armstrong Pumps 174034MF-013 Circulator Pump (H-32 BF) 1-Phase 1/6Hp 115V 60 Hz

SKU: 174034MF-013

UNSPSC: 40151500 Tariff HS Code: 8501104040

Brand:

Rating: (1)

Quantity	Price	Stock
4 Usually Ships 2 - 4 Weeks	$1,107.52 /ea	4

Add to Cart

Add to Wishlist

Add to Cart

Add to Wishlist

The Armstrong 174034MF-013 (H-32 BF) is a single-phase, three-piece circulator pump that operates at 1/6 HP, 115V, and 60 Hz. It has a motor, detachable pump, and bearing assembly. CSA Listed, ensuring safety compliance.

Features

14 ft. Head
38 GPM Flow Rate
Built-in Thermal Overload Protection
Cast Iron Body with a Non-Ferrous Impeller
Maintenance-Free Bearings (No Lubrication Required)
225°F Maximum Temperature
175 PSI Maximum Pressure

Ideal for applications such as hydronic heating and cooling, multi-stage zoning, domestic water systems, and general industrial service. Not for use in potable water systems—this pump does not comply with the Safe Drinking Water Act.

Compatible with 1", 1-1/4", or 1-1/2" flanges, it is designed to be mounted in-line near a water heater or boiler. Directly replaces Bell & Gossett 102210, Grainger 4RC93, and Armstrong 174034-013 pumps.

Number of Phase	Single-Phase
Electrical Ratings	1/6Hp, 115V, 60 Hz
Pump Design	Three-Piece
Maximum Feet of Head	14 ft.
Maximum Flow Rate	38 gpm
Maximum Pressure Rating	175 psi
Maximum Temperature Rating	225°F
Body Material	Cast Iron
Impeller Material	Non-Ferrous
Mounting Location	In-Line

Download Product Information:

Armstrong S&H Series In-Line Circulating Pumps Brochure

Armstrong S&H Series In-Line Circulating Pumps Installation and Operating Instructions
