Housing Material | Glass Filled Nylon |
---|---|
Diaphragm | Neoprene, rolling type |
Spring | Retract actuator shaft on loss of air pressure |
Ambient Temperature Range | -20F to 140F (-29C to 60C) |
Supply Air Pressure | Clean, dry, oil free air required |
Nominal Pressure Limit | 20 PSIG (138 kPa) |
Maximum Pressure | 30 PSIG (207 kPa) |
Air Consumption (Position Models) | 0.017 scfm |
Connections | Barbed fitting for 1/4" O.D. plastic tubing |
