| Model No. | Pressure Range | Adjustable Range | Approximately Deadband (Actuation Value) psi (bar) |
Proof Pressure psi (bar) |
|||
| Decreasing psi (bar) |
Increasing psi (bar) |
||||||
| Min. | Max. | Min. | Max. | ||||
| MSPS-EE05-Q71 | 05 | .5 (.03) | 4.5 (.03) | 1 (.07) | 5 (.3) | .2 - .5 (.01 - .03) | 100 (6.7) |
| Enclosure | Anodized aluminum base plate; Polysulfone housing |
|---|---|
| Seals & Diaphragms | Buna-N |
| Process Fitting | 304 Stainless Steel |
| Accuracy | +/- 2.0% of the adjustable range |
| Operating Temperature | 20F to 165F (-7C to 74C) |
| Limit Switch | SPST Normally Open; 3 Amps at 125/250 VAC |
| Enclosure | MSPS Stripped Version |
Download Product Information:
By RAMARAO
from LONDON ON
Yes, I would recommend this product to a friend or co-worker
My experience in purchasing the item was fine and customer service was good, thank you. But, after I purchased the component yourselves came up with a discount of 60% savings on your component sales. So, I am left to think whether I should receive the same on my order too! As my purchase and your promotions just happened successively. If I am eligible for a refund pl. do so. Otherwise it is ok, my bad luck!
By Steven
from
Yes, I would recommend this product to a friend or co-worker
Product delivered quickly and as represented. Performed well and resolved my issue.
