Max. working pressure = 46 bar.
Max. test pressure = 60 bar.
Temperature of the medium: -50 - +140°C.
| TYPE CODE | NRV 16s |
| WEIGHT | 0.178 Kg |
| APPROVAL | C UL US LISTED, EAC |
| CV VALUE | 4,160 gpm US |
| DIRECTION | Straightway |
| EAN NO. | 5702422025122 |
| IDENTICAL PROD. | 020-1150 |
| INLET TYPE | SOLDER, ODF |
| INLET SIZE | 5/8 IN |
| INLET SIZE | 16,00 mm |
| KV VALUE | 3,600 m3/h |
| MWP | 46,0 bar |
| MWP | 667 psig |
| MIN. PRESS. DROP | 0,05 bar |
| MIN. PRESS. DROP | 0,7 psi |
| OUTLET TYPE | SOLDER, ODF |
| OUTLET SIZE | 5/8 IN |
| OUTLET SIZE | 16,00 mm |
| PACK FORMAT | Multi pack |
| PROD. GROUP | Check valves |
| PROD. NAME | Check valve |
| PACK QTY. | 24 pc |
| REFRIGERANT | HC |
| REFRIGERANT | HCFC/HFC |
| TEMP. RANGE | -50 - 140 °C |
| TEMP. RANGE | -58 - 285 °F |
| UL APPROVAL FILE | REFRIGERANT VALVE 53R0 |
