Honeywell DC3501CE3000210000 Single & Dual Loop Digital Controller for use with 24Vac/dc Power plus Current Output (4 to 20mA, 0 to 20 mA). The relay output is 3 E-M Relay (5 Amp Form C). Communication 10 Base-T Ethernet (Modbus RTU) + (4) Digital Inputs. The software has standard functions including Accutune. Single Loop control.
The Universal Digital Controller packs new powerful features in the popular 1/4 DIN size. Unmatched application power includes an Infrared (IR) Configuration interface, three universal analog inputs, two loops of control, and two Math Algorithms. When these are combined with the Accutune III™ tuning with fuzzy logic overshoot suppression, the result is price/performance leadership. Application flexibility is assured by the universal analog inputs, universal AC power supply, four digital inputs, a maximum of seven analog and digital outputs, Infrared, RS422/485 Modbus RTU, or Ethernet 10Base-T TCP/IP Modbus communication protocols, simple configuration plus total field upgrade capability for any optional feature.
Features:
• 3 Universal Analog Inputs (can be configured to operate as 1 Universal and 4 High Level Inputs)
• 0.10% Accuracy
• Fast scanning rate (166ms)
• Up to 3 Analog Outputs
• Up to 5 Digital Outputs
• 4 Digital Inputs
• Math Functions
• Ethernet or RS-485 communication
• Infrared PC & Pocket PC configuration
• Healthwatch Maintenance Tool
• NEMA4X and IP66 front face protection
• Multilanguage prompts
• 1/4 DIN Size Easily Field Upgradeable
• Bright, dual displays
