Johnson Controls S350AA-1 Add-On Stager Module 1-30Fdiff

Johnson Controls S350AA-1 Add-On Stager Module 1-30Fdiff
Images for general purposes only. Actual may be different than depicted.
Johnson Controls S350AA-1 Add-On Stager Module 1-30Fdiff Johnson Controls S350AA-1 Add-On Stager Module 1 to 30°F Differential Johnson Controls S350AA-1 Add-On Stager Module SPDT Relay Output Johnson Controls S350AA-1 Temperature Stage Module

Johnson Controls S350AA-1 Add-On Stager Module 1-30Fdiff

SKU: S350AA-1
Rating: (1)
Quantity Price Stock
1
Usually Ships 1 - 2 Weeks
$138.93     /ea
1
0
$0.00
0
$0.00
0
S350AA-1
The S350AA-1 is a stage module that has a differential adjustment and offset range of 1 to 30°F.  It has a 1 VA maximum power consumption and features an SPDT relay output with front panel LED that lights up when the unit is energized.  UL-listed.

The temperature stage module is suitable for use with system 350 control applications.  The unit is designed a NEMA 1 high thermoplastic enclosure that provides excellent protection within 0 to 95% non condensing ambient humidity.  The mode of operation can be selected by allowing independent relay energization whether under or below the setpoint for cooling or heating.

The S350AA-1 can be mounted to wall or 35 mm DIN rail mounting with plug-together connections that removes wiring between modules for quick and easy installation.  The WHA29A-600R (3 ft), WHA29A-603R (25 ft), and WHA29A-604R (50 Ft) cable accessories are also available.
Differential Adjustment Range 1 to 30°F
Offset Range 1 to 30°F
Power Consumption 1 VA
Output Relay SPDT
Amperage 10A
Horsepower 1/2 hp
Approvals UL-listed
Enclosure Rating NEMA 1
Mounting Wall or DIN Rail
Ambient Humidity 0 to 95% RH (Non-condensing)

By Jim

from

Yes, I would recommend this product to a friend or co-worker

5.0 Great control

Worked 1st time
