All VTA Series Three Way Air Switching Valves

come equipped with a factory mounted V-3000

Series Exposed Pneumatic Actuator, and are

available with or without a variety of factory installed

adaptor fitting configurations (as noted in Table 1).

The VTA Valve is also furnished with a split-clamp

bracket for surface mounting in an upright position.

The V-3000 Series Actuator features a die cast

aluminum housing and a molded, synthetic rubber

diaphragm design. This molded diaphragm

provides a constant effective area throughout the

valve stem stroke. The actuator can be easily

removed or repositioned by loosening a single set

screw without disturbing the remainder of the valve

assembly.

The cast brass valve body complies with ANSI and

ISA Standards, providing certifiable control valve

accuracy and performance. The valve body

features an integral seat and a molded composition

disc that provides tight shutoff. An arrow is cast into

the valve body indicating the direction of flow for

proper piping.
