The VA9905-KGA-2 is a rotary actuator that operates at 24V with a 0-10VDC proportional control signal.  It has a 5Nm torque rating, 4.7 VA power consumption, and a 32 to 140°F operating temperature range with a plenum-rated cable & NEMA5/IP54 enclosure protection.  The actuator complies with UL, CE Mark, CSA, and RCM standards.

The non-spring return actuator is designed for direct mounting on VG1600 Series 270° Six-Way Ball Valves, making it ideal for controlling heating and cooling operational modes.  It offers a 270° operational range for precise valve positioning and a microprocessor-controlled brushless DC motor that provides reliable performance.  It also has a position indicator handle and manual override providing added convenience for manual adjustments.

The VA9905-KGA-2 is easy to install and uses plastic posts and tabs to align with the valve flange and stem notch.  It is also equipped with an eight-position Dip Switch for easy configuration.
