Approvals and Standards: CSA Design Certified

Type of Fuel: Natural Gas, LPG

Ignition Type: Intermittent Pilot

Ignition Source: Internal high voltage spark generator

Ignition Between Trial Time: 5-minute delay after failed trial

Ignition Sequence: Continuous retry

Ignition Trial Time: 90 sec

Ignition Trials to Lockout: Continuous retry

Pre-Purge: None

Lockout Timing: Continuous retry

Flame Failure Response Time: 2 sec max

Typical Ignition Hardware: Q345, Q3451

Igniter-Sensor Rod: Single

Typical Gas Control: VR8204, VR8304

Product Dimensions: 5.44 in (W) x 3.94 in (H) x 2.63 in (D) / 138 mm x 100 mm x 67 mm

Maximum Valve Load: 1 A Pilot, 1 A Main @ 24 V AC

Frequency: 60 Hz

Ambient Operating Temperature: -40 °F to 175 °F / -40 °C to 79 °C
