Watts Series G2 Full Port Lead Free Bronze Ball Valve
The Watts G2 series offers 2-Piece, Full Port Lead Free Bronze Ball valve used commercial and industrial applications. The valves feature a blowout proof stem and a full-port orifice to ensure minimal pressure drop. The G2 series offers solder and NPT end-connections with Lead Free NSF-372 certification.
This 0450101 3/8 inch lead free 2-piece full port bronze ball valve with a threaded end connection. A full port orifice ensures minimal pressure drop and the overall robust design provides lasting service. This ball valve is rated for 600 WOG/150 WSP.
Features:
| Ball Material | Chrome Plated Brass |
|---|---|
| Body Material | Bronze |
| Inlet/Outlet Connection Size | 3/8 IN |
| Inlet/Outlet Connection Type | Female Threaded |
| Inlet Thread Type | NPT |
| Outlet Thread Type | FPT |
| Temperature Range | 0°F - 400°F (-18°C – 205°C) @ 50psi (3.4 bar |
| Pressure Range | 600psi (41 bar) WOG, non-shock; 150psi (10.3 bar) WSP |
| Seat/Stem Packing/Thrust Washer Material | Virgin PTFE |
Download Product Information:
Watts G2 Series LFB6080G2 Full Port Ball Valves Technical Datasheet
