Fasco D291A Dual Shaft Motor 4-Speed 115V Single-Phase 42 Frame Dual Shaft

Name: Fasco D291A Dual Shaft Motor 4-Speed 115V Single-Phase 42 Frame Dual Shaft
Brand: Fasco
SKU: D291A
Price: 292.07 USD
Availability: InStock

Images for general purposes only. Actual may be different than depicted.

Fasco D291A Dual Shaft Motor 4-Speed 115V Single-Phase 42 Frame Dual Shaft

SKU: D291A

UNSPSC: 26101100

Brand:

Rating:

Quantity	Price	Stock
300 Usually Ships 1 - 2 Weeks	$292.07 /ea	300

Add to Cart

Add to Wishlist

The D291A found on this page, is a direct replacement for the following obsolete item(s):

Obsolete Product	SKU
Fasco D291 Fan Coil Air-Conditioning & Heating Unit Motor 5" Diameter 1/10 Hp 115 V 1050 RPM 4-Speed	D291 Brand Fasco

Add to Cart

Add to Wishlist

The D291A is a thermally protected motor that has 115V, 2.2A, and 60 Hz electrical rating with 4-speed settings. It has a 42 frame size, 1/10,1/15,1/25,1/40 HP, and rotates in up to 1050 RPM in a counterclockwise direction. Ul-recognized and CSA-certified.

The single-phase motor is used to turn the fan to send conditioned air into the home. The unit features rolled steel, resilient base, class B insulation, and open air over enclosure allowing excellent performance in harsh conditions.

The D291A directly replaces part number Fasco D291 and A.O. Smith DA3E206N.

Number of Poles	6 Poles
Output Horsepower	1/10,1/15,1/25,1/40 HP
Number of Speeds	4-Speeds
Ambient Temperature	40°C
Rotation Speed	1050 RPM
Frame Size	42
Frequency	60 Hz
Voltage	115V
Shaft Type	Flat
Shaft Diameter	1/2"

Download Product Information:

Fasco D291A Dual Shaft Motor Technical Datasheet
